General V24 |
Scroll |
1.Added library Graphic_2023.lyt to the \Sys folder, replacing library Graphic.lyt. All documents created in KOMPAS-3D v24 use the Graphic_2023.lyt library; the Graphic.lyt library is not used, but is present in the
\Sys folder to support previously created documents.
Library Graphic_2023.lyt contains:
•new elements:
•layout variants with the column "Version", e.g., Drawing. Group Version. First sheet. GOST R 2.104-2023, etc.;
•variant change notice forms with boxes for the proposal to be reissued, e.g., Notice of Change with PR. First sheet. GOST R 2.503-2023 F1 etc.;
•variants (for different formats and sheet orientations) of change notification forms for automated electronic document management systems, e.g. Change Notificе for ASED. First sheet. GOST R 2.503-2023 F2, etc.;
•document styles of the List type with lines for the customer's representative, as well as the necessary designs for them;
•updated in accordance with GOST R 2.104-2023 and GOST R 2.503-2023:
•title blocks;
•designs of drawings;
•designs of text documents;
•unchanged title blocks, designs, and styles from the Graphic.lyt library, except for those intended for building (use the SPDS_GR_2022.lyt library when creating documents for building).
2.Improved dialog box for setting system and current document parameters (invoked by command Settings - Parameters...):
•Settings are represented by a general list, scrolling through which it is available to view all the parameters accessible for change. In addition, it is available to select a separate section and view the settings located in it and in its subsections. Previously, to access a specific parameter, it was necessary to select a tab, and then to select a section (and subsection) on it.
•Added the ability to search by names of sections and controls (options, lists, etc.) to the dialog box.
•For some parameters, the controls that are used for customization have been changed, for example, the options group has been replaced by a list of options. Some parameters have been moved to other sections to group settings more logically; the set of sections is generally the same as before.
•General interface settings have also become available in the dialog: selection of colors, language and icon size, keyboard settings, tab positions and remembering the last command. Previously, these parameters could only be changed in the menu of the Interface settings button in the KOMPAS-3D window header.
3.The default setting of KOMPAS-3D has been changed; the following parameters have been changed:
•automatic obtaining of a license for KOMPAS-3D upon loading: was disabled, became enabled;
•default name of the KOMPAS document file: it was Name + Designation, it became Designation+ Name;
•default scheme of standard views: there was Z-axonometry, became Y-axonometry.
4.The font of KOMPASS documents of all types has been changed: now the unicode font GOST type AU is used in newly created documents. The documents of previous versions used a non-unicode font GOST type A. To ensure this replacement, the settings of the new documents, templates, title blocks and layouts, the source file of the GRAPHIC.SSS special characters and the binary file of the GRAPHIC.BSS special characters, the GOST type AU and GOST type BU fonts were adjusted.
5.New features when creating and editing links in the dialog box Link:
•rounding to the specified sign is now available for link to a property—provided that the property value is a number (previously rounding was only available for variable links);
•if a broken link is edited, the dialog displays the text it last contained and a warning that the source of the link was not found.
6.Added the ability to include a scroll bar in the additional Design tree. The corresponding option can be found in the System — Screen — Background color section of the setup dialog.
7.Added the possibility to delete rows in lists and tables in the Parameter panel and in the Product BOM panel with the key <Delete>..
8.Files Graphic.kds and Graphic.kdsp, defining the set of available document codes and the order of sorting documents by code, are corrected according to GOST R 2.102-2023. The files are located in the \Sys folder.
9.The size and location of the KOMPAS-3D window is now saved between working sessions. Previously, in a new session, the KOMPAS-3D window opened in full screen.
•
